AAMA SPECIFICATIONS for Powder Coating & PVDF Coating

As a normal practice, architects and building owners determine the performance specification required, along with its finish and colour. In order to ensure the coating performance expected, for a given application, one of the three AAMA specifications is adhered to: AAMA 2603, AAMA 2604, or AAMA 2605. These three specifications apply to progressively stronger levels, as indicated by South Florida outdoor exposure and laboratory accelerated testing results. Ameco group is 100% compliant of all AAMA voluntary specifications.

Best of Voluntary AAMA Specifications and other standards for Architectural Powder Coating & PVDF Coating.

Specification 2603 (Powder Coating) 2604 (Powder Coating) 2605 (PVDF Coating)
South Florida Weathering :
Color retention 1 year: "slight" Fade 5 yrs: Fade = 5 Delta E 10 yrs: Fade = 5 Delta E
Chalk resistance 1 year: "slight" chalk 5 yrs: Chalk = 8 10 yrs: Chalk = 8
Gloss retention - 5 yrs: 30% retention 10 yrs: 50% retention
Erosion resistance - 5 yrs: 10% loss 10 yrs: 10% loss

Dry film thickness : 60 to 80 micron avg. 60 to 80 micron avg. 35 to 45 micron avg

Pretreatment System : Chrome or Chrome Free Chrome or Chrome Free Chrome or Chrome Free & primer

Accelerated Testing :
Salt Spray corrosion resistance 1,500 hours 3,000 hours 4,000 hours

Warranty : 10 Years 15 Years 25 Years

AAMA SPECIFICATIONS for Anodizing

In order to ensure the anodize performance expected for an architectural / commercial applications, AAMA 611-14 specifications are preferred for Anodizing. Beyond the stringent standards and regulations, Ameco Group offers specifiable differences that contribute to a project’s durability and sustainability. Ameco Group is 100% compliant of all AAMA specifications for anodizing.

AAMA 611 Specification for Anodizing

Specification Class II Class I
South Florida Weathering :
Color retention Color retention 10 yrs: Fade = 5 Delta E 10 yrs: Fade = 5 Delta E
Chalk resistance N/A N/A
Gloss retention 15 unit variation 15 unit variation

Dry film thickness : 25 micron 20 micron

Pretreatment System : 11 tank cleaning & etching system 11 tank cleaning & etching system

Accelerated Testing :
Salt Spray 1,000 hours 3,000 hours
Additional Specification Durable powder coating Super – durable powder coating Hyper Durable PVDF coating
Outdoor weathering resistance 1 year < 8 rating 5 years < 8 rating 10 years < 8 rating for colours < 6 rating for white
Impact resistance No film removal at initial test (Not subject to weathering exposure)
Boiling water film adhesion No loss of adhesion after 20 minutes in 2120 F Water
Colour uniformity No variation outside of limits, established by colour range sample approval
Abrasion resistance - Abrasion coefficient > 20 . Abrasion coefficient > 40
